Product Details
＋
SPECIFICATION
| Panel Type | 17″ (4:3) LED Monitor with Glass Front |
| Case Type | Metal |
| Maximum Resolution | 1280 (H) x 1024 (V) |
| Active Display Area | 337.920 x 270.336 (V) mm |
| Pixel Pitch | 0.264 (H) x 0.264 (V) mm |
| Bezel Thickness | Sides: 14.3mm Top: 17.6mm Bottom: 17.6mm |
| Contrast Ratio | 1000 : 1 Ratio |
| Brightness | 250 cd/ m2 |
| Response Time | 5ms |
| Viewing Angle | U/D: 85° / 85° L/R: 89° / 89° |
| Display Colours | 16.7 M |
| Video Synchronization | TTL Positive or Negative |
| PC Compatible Frequency | 30-80KHz(H) / 50-75Hz(V) |
| Adjustable Colour Temperature | Yes |
| Video Compatiblity | Multi-Standard for NTSC / PAL |
| Aspect Ratio | 4 : 3 |
| VGA Auto Frequency correction | Yes |
| Speakers | Multimedia Speakers |
| Number of Speakers | Right x 1, Left x 1 (2.5W) |
| Sound Demodulation | Stereo. Audio |
| Mute | Yes |
| Work Humidity | 20 % – 70 % |
| Work Temperature | -10 to 50 °C |
| Volume /- Power On/Off | Yes |
IN/OUT INTERFACE
| Video Interface | HDMI x1 VGA x 1 BNC x 2 In / BNC x 1 Out |
| Audio Interface | Audio in x 1, Audio L x 1, Audio R x 1 |
| Power Interface | DC In x 1 |
| Termination | 75 Ohms (Automatic termination) |
| Safety & EMC Certification | Energy Star / CE / FCC / ROHS / WEEE |
| Stand Type | Picture Frame |
| Vesa Standard Mount | 100 x 100mm |
| Colour | Black |
| Packing Dimension | 460 (W) x 460 (H) x 150 (D) mm |
| Button Position | Right Hand Side / Back |
| NET Weight | 4.1 Kgs |
| GROSS Weight | 5.4 Kgs |
POWER
- Power Supply: 12VDC, 3 amp
- Power Consumption: < 18W in “ON”
OSD CONTROLS
Contrast, Brightness, OSD Duration, H-Position, V-Position, Language, Colour Temp, Backlight, Sleep Timer, Sound, Memory Recall.
OSD LANGUAGE
English, French, German, Spanish, Italian, Russian, Polish and Portuguese
ACCESSORIES
Power Supply / Kettle Lead / HDMI Cable / Remote Control / User Manual
