Server Technology PRO1 Switched PDU C1W24VS-DEFA13A1 - Master - power distribution unit (rack-mountable) - AC 208 V - 12.5 kW - 3-phase - Ethernet 10/100, RS-232 - input: CS8365 - output connectors: 24 (6 x IEC 60320 C19, 18 x IEC 60320 C13)

• Outlet control
  On Switched rack PDUs, cycle power to individual outlets or groups of outlets to reboot servers. Or, power off unused receptacles.
• High-retention locking outlets
  Receptacles have high retention and are compatible with P-lock type power cords.
• Auto-flip current display
  Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
• Hot-swap network card
  Network access is ensured when power is lost to the master unit with backup power provided by the primary link unit.
• Star multi-linking
  Provides the ability to link up to four power circuits using one IP address. Primary link provides backup power to network card.

The Server Technology PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in web and CLI interfaces as well as through SNMP.

• Outlet control
• High-retention locking outlets
• Auto-flip current display
• Hot-swap network card
• Star multi-linking
